Grease Duct Fire Wrap Details

Installed as a two layer system fyrewrap elite 1 5 complies with the international mechanical code imc and uniform mechanical code umc.

Grease duct fire wrap details.

Whatever your application fastwrap duct insulation provides a highly capable easy to install and cost effective fire protection solution. Thin lightweight and flexible 3m fire barrier duct wrap 615 provides excellent insulating capabilities and offers a space saving alternative to traditional bulky fire protection methods obtained through a gypsum wall shaft or enclosure. Material and equipment 24 or 48 wide by 1 1 2 38 1mm thick by 25 ft. Use 3m fsk facing tape 3320 3m aluminium foil tape 425 or similar system compatible heat resistant tape to seal any cut edges of the duct wrap.

762cm standard length 3m fire barrier duct wrap 615 blanket 60 96cm or 121 92cm by 38 1mm by 762cm. Protect both grease ducts and air ducts in an easy to install format lightweight flexible while passing the necessary fire tests to achieve up to 2 hour fire resistance requirements. 3m fire barrier duct wrap 615 is the only fire rated duct wrap product you ll ever need to help protect both grease ducts and air ducts while passing the necessary fire tests to achieve up to 2 hour fire resistance requirements. 3mtm fire barrier duct wrap 15a is a fire resistant wrap consisting of a patented inorganic blanket encapsulated with a scrim reinforced foil.

It is third party certified to astm e2336 grease duct test standard and iso 6944 air duct test standard. Fyrewrap elite 1 5 duct insulation is a two layer flexible enclosure for two hour rated commercial kitchen grease ducts. Unifrax fyrewrap elite 1 5 duct insulation wrap is a flexible enclosure for 1 and 2 hour fire rated commercial kitchen grease ducts range hoods and hazardous exhaust ducts including chemical fume ducts. This wrap is commonly used in commercial kitchen grease ducts as well as ventilation ducts.

Fyrewrap elite 1 5 duct insulation is tested per astm e2336 and is acceptable as an alternate to a traditional fire rated shaft. We offers 2 3 and 4 hour blast resistant and fire rated ducts duraducts including zero clearance kitchen grease duct lab exhaust and access doors to allow for cleaning. It is used to fire rate commercial kitchen grease ducts and is a proven alternative to 1 or 2 hour fire resistant rated shaft enclosures. This non asbestos wrap contains a.
